Napajanje 650W Thermaltake Smart BM2 80+ Bronze/Modular, PS-SPD-0650MNFABE-1

Opis

P/N
PS-SPD-0650MNFABU-1

WATTS
650W

RGB FAN
No

MODEL
SP-650AH3CCB-B | SP-650AH3CLB-B

TYPE
ATX 12V v2.4 and EPS v2.92

MAX. OUTPUT CAPACITY
650W

COLOR
Black

DIMENSION ( W / H / D )
150mm(W) x 86mm(H) x 160mm(D)

PFC (POWER FACTOR CORRECTION)
Active PFC

POWER GOOD SIGNAL
100-500 msec

HOLD UP TIME
> 12msec at 80% of full load at 230Vac input

INPUT CURRENT
10A max. | 6 – 12A

INPUT FREQUENCY RANGE
47Hz -63Hz

INPUT VOLTAGE
100V-240V~

OPERATING TEMPERATURE
0°C to +40°C | +5°C to +40°C

OPERATING HUMIDITY
20% to 90%,non-condensing | 20% to 85%,non-condensing

STORAGE TEMPERATURE
-20 °C to +70 °C | -40 °C to +55 °C

STORAGE HUMIDITY
5% to 95%, non-condensing | 10% to 95%, non-condensing

COOLING SYSTEM
140mm Fan: 2300 R.P.M. ± 10%

EFFICIENCY
Meet 80 PLUS®Bronze at 115Vac input.

MTBF
100,000 hrs minimum

SAFETY APPROVAL
cTUVus/TUV/CE/FCC/S-mark/EAC/BSMI/C-TICK/CCC

PCI-E 6+2PIN
4

PROTECTION
OVP ,OPP, OCP, OTP
